ZD Adventa Series

Aluminium profile LED lighting fixture with extruded polycarbonate environmental friendly, energy efficient ready to use pack.

Features & Benefits

Icon 1

Delivers excellent illumination

& comfort in high

ceiling areas

Icon 2

Long life & photobiologically

safe LEDs

Icon 3

High performance electronic

driver ensures zero

maintenance

Icon 4

No harmful UV & IR radiations

Icon 6

Environment-friendly as it

does not contain Mercury

Icon 7

Instant light with low

running temperatures

Icon 8

Operating temperature :

-10° C to +45° C

Icon 9

Operating voltage range :

120 V - 300 V

Icon 10

Average LED life :

20000 hours

Technical Specifications

Wattage18W36W
Product CodeCLB18WSCLB36WS
Dimension (mm)LXWXH (584X50X25)LXWXH (1182X48X25)
Cutout/Pole Dia (mm)NANA
Body ColorWhiteWhite
Operating Voltage220 - 240220 - 240
Power Factor>0.9>0.9
Total Lumen18003600
Lumen Efficacy(LM/W)100100
CRI>80>80
CCT6500K/4000K/3000K6500K/4000K/3000K
Beam Angle120°120°
Housing MaterialPoly Carbonet + AL. HeatsinkPoly Carbonet + AL. Heatsink
