Features & Benefits
Light Fixtures can be changed without disturbing surface interior.
Long life & photobiologically
safe LEDs
No harmful UV & IR radiations
Environment-friendly as it
does not contain Mercury
Instant light with low
running temperatures
Operating temperature :
-10° C to +45° C
Operating voltage range :
90 - 300 Vac
Long life :
25000 hours
Technical Specifications
| Wattage | 40W | 50W | 60W | 70W |
|---|---|---|---|---|
| Shape | Square | Square | Square | Square |
| Product Code | CLAD03W | CLAD06W | CLAD12W | CLAD18W |
| Wattage | 03W | 06W | 12W | 18W |
| Dimension Outer(mm) | (LXWXH) 85x85x25 | (LXWXH) 118x118x25 | (LXWXH) 170x170x25 | (LXWXH) 225x225x25 |
| Dimension Cutout(mm) | (LXWXH) 67x67mm | (LXWXH) 107x107mm | (LXWXH) 154x154mm | (LXWXH) 205 X 205mm |
| CRI | >80 | >80 | >80 | >80 |
| System Lumen | 100-110Lm/W | 100-110Lm/W | 100-110Lm/W | 100-110Lm/W |
| Input | 90 ~ 300 Vac | 90 ~ 300 Vac | 90 ~ 300 Vac | 90 ~ 300 Vac |
| Surge Protection | Upto 4KV | Upto 4KV | Upto 4KV | Upto 4KV |
| Voltage | 120-300Vac, 50Hz | 120-300Vac, 50Hz | 120-300Vac, 50Hz | 120-300Vac, 50Hz |
| Housing Material | Aluminium Pressure Die Casted Housing With Powder Coating | Aluminium Pressure Die Casted Housing With Powder Coating | Aluminium Pressure Die Casted Housing With Powder Coating | Aluminium Pressure Die Casted Housing With Powder Coating |
