Exter
Features & Benefits
Long life & photobiologically
safe LEDs
Ip65
No harmful UV & IR radiations
Environment-friendly as it
does not contain Mercury
Instant light with low
running temperatures
Operating temperature :
-10° C to +45° C
Average LED life :
25000 hours
Technical Specifications
| Wattage | 05W | 07W | 09W | 12W | 15W | 20W |
|---|---|---|---|---|---|---|
| Product Code | CLCSPL05 | CLCSPL07 | CLCSPL09 | CLCSPL12 | CLCSPL15 | CLCSPL20 |
| DIMENSION Dia| H (mm) | 72x265 | 72x265 | 80x280 | 80x280 | 80x280 | 80x280 |
| Operating Voltage | 90-300Vac, 50Hz | 90-300Vac, 50Hz | 90-300Vac, 50Hz | 90-300Vac, 50Hz | 90-300Vac, 50Hz | 90-300Vac, 50Hz |
| Power Factor | >0.90 | >0.90 | >0.90 | >0.90 | >0.90 | >0.90 |
| System Lumen(LM/W) | 100-110 | 100-110 | 100-110 | 100-110 | 100-110 | 100-110 |
| CRI | >80 | >80 | >80 | >80 | >80 | >80 |
| CCT | 4KV | 4KV | 4KV | 4KV | 4KV | 4KV |
| Color Temperature |  | | | | | |
